C325-UA-HD series
铝芯聚氨酯
feature of product
*Features：Plastic pedal brake design, anti collision and quiet
*Top plate thickness
3 mm
*Kingpin size
16 mm
*Surface Finish
Blue zinc plated
Bead structure:
| Rigid | Swivel | Brake Castot(Part No.) | Dia. x Width | Offset (w/ Brake) | Total Height | Load Capacity |
|---|---|---|---|---|---|---|
| C325R/UA3140CB1y | C325S/UA3140CB1y | C325T/UA3140CB1y | 76x32 | 71(117) | 106 | 100 |
| C325R/UA4140CB2y/HD | C325S/UA4140CB2y/HD | C325T/UA4140CB2y/HD | 101x32 | 84(117) | 131 | 120 |
| C325R/UA5140CB2y/HD | C325S/UA5140CB2y/HD | C325T/UA5140CB2y/HD | 127x32 | 96(117) | 159 | 150 |
Product note
长度单位为"mm"
