C325-PU series
C325 SD LIGHT DUTY
feature of product
*Brake Release design is easyto use.
*Top plate thickness
3 mm
*Kingpin size
16 mm
*Surface Finish
Blue zinc plated
Bead structure:
| Rigid | Swivel | Total Brake | Dia. x Width | Offset (w/ Brake) | Total Height | Load Capacity |
|---|---|---|---|---|---|---|
| C325R/PU0753 | C325S/PU0753 | C325T/PU0753 | 75x32 | 71(117) | 106 | 100 |
| C325R/PU1032 | C325S/PU1032 | C325T/PU1032 | 100X32 | 84(117) | 131 | 120 |
| C325R/PU1232 | C325S/PU1232 | C325T/PU1232 | 125x32 | 96(117) | 159 | 150 |
Product note
长度单位为"mm"
