C610-KU series

Blue Bracket Heavy Duty Herdar Pullprene® Polyurethane thick crown tread mold-on Cast iron castors

*Classic design, extremely durable,higher load rating,

smooth swivel action due to thrust and tappered bearing.

*Top plate thickness

10 mm

*Kingpin size

16-20 mm

*Surface Finish

Blue paint

Bead structure:

Rigid	Swivel	Total Brake	Dia. x Width	Offset (w/ Brake)	Total Height	Load Capacity

C610R/KU1050	C610S/KU1050	C610TJ/KU1050	100x50	85	150	350
C610R/KU1350/TG	C610S/KU1350/TG	C610TJ/KU1350/TG	130x50	105	173	400
C610R/KU1550/TG	C610S/KU1550/TG	C610TJ/KU1550/TG	150x50	115	200	500
C610R/KU2050/TG	C610S/KU2050/TG	C610TJ/KU2050/TG	200x50	150	250	600

长度单位为"mm"
